Application: Final or return filtration for clean rooms with turbulent flow.

Type: HEPA /ULPA filtering panel

Frame: Extruded and anodised aluminium.

Gasket: Half round continuous expanded polyurethane.

Media: Glass fibre paper.

Separator: Hot-melt beads.

Sealant: Polyurethane.

Grid: Mild steel painted grille upstream and downstream.

EN 1822 efficiency:  H14.U15

MPPS efficiency: H14: ≥99.995%.; U15≥99.9995%.;

DOP efficiency: H14: ≥ 99.999%.; U15 ≥99.999%.;

Recommended final pressure drop: 600 Pa.

Maximum flow rate: See table, use nominal values otherwise a reduction in efficiency may
occur.

Temperature: 70°C maximum in continuous service.

Test: : 100% individually scanned to EN 1822.

Mounting system: Mechanical clamping structure, Terminal housings.

Optional: Alternative frame materials and size available on request.

model	Outside dimensions (mm)	Rated airflow (m3/h)	Initial resistance (Pa)	Efficiency (%)	Dust capacity (g)
GXW-7J	610×610×50	700	≤220 or ≤140 (HV) For U14 ≤250or ≤180 （HV) For U15	≥99.99 Or≥99.999	450
GXW-10J1	915×610×50	1000		≥99.99 Or≥99.999	680
GXW-14J	1220×610×50	1400		≥99.99 Or≥99.999	900
GXW-10J2	610×610×69	1000		≥99.99 Or≥99.999	560
GXW-15J	915×610×69	1500		≥99.99 Or≥99.999	840
GXW-20J	1220×610×69	2000		≥99.99 Or≥99.999	1120
GXW-12J	610×610×80	1200		≥99.99 Or≥99.999	650
GXW-14J	610×610×90	1400		≥99.99 Or≥99.999	750
GXW-16J	610×610×100	1600		≥99.99 Or≥99.999	850
GXW-18J	1170×570×69	1800		≥99.99 Or≥99.999	1000
GXW-22J	1170×570×80	2200		≥99.99 Or≥99.999	1250
GXW-25J	1220×610×80	2500		≥99.99 Or≥99.999	1300
GXW-28J	1220×610×90	2800		≥99.99 Or≥99.999	1500
GXW-32J	1220×610×100	3200		≥99.99 Or≥99.999	1700
GXW-36J	1220×1220×69	3600		≥99.99 Or≥99.999	2000
